Sensitive element with stainless steel membrane, laser welded. Metallic frame. Cover in shockproof thermoplastic material. Output connections with PVC cable gland. Fixed differential. Female connection G 1/4 (17 mm key). Maximum temperature of the controlled fluid: 120 °C. Pressure switch body admissible temperature: -35 ÷ 60°C. Storage and transport temperature: -35 ÷ 60°C. Unit weight: 0,43 Kg B12AN. Unit weight: 0,44 Kg B12BN. ACCESSORIES:G1/2 cable gland in V0 self-extinguishing, shockproof thermoplastic material, code: 303298LAIP44 protection casing IP44, code: 2593367Electric featuresRated insulation voltage Ui 415V~Continuous duty rated current Ith 16A
