Elements in contact with the fluid are in stainless steel, laser welded. Base, cover in V0 self-extinguishing, shockproof thermoplastic material. Output connections with PVC cable gland. Sensing element with stainless steel membrane. Internal regulation: the cover is made to be welded after setting and testing. Maximum temperature of the controlled fluid 120 °C. Pressure switch body admissible temperature -35 ÷ 80°C. Storage and transport temperature -35 ÷ 80 °C. Unit weight 0. 14 Kg. ACCESSORIESG1/2 cable gland in V0 self-exting, code: 303298LAElectric featuresNominal insulation tension Ui 380V~Continuous duty nominal current Ith 15A
